Piston Operated Mixers
POM-Series
for existing Vaporizers





  • FEATURES
    • No rubber diaphragms to dry out and stiffen.
    • A close tolerance guide for the piston is internal, away from air & gas flow.
    • Unique air labyrinth piston seal.
    • The piston does not touch bore.
    • There are no piston rings to seize: the labyrinth acts as a seal.
    • There is no external piping.
    • Operating bleeds and parts are integral within the valve, thereby reducing damage possibilities.
    • A proven technology that is used in Rolls Royce and Jaguar engines.
    • Available state-of-the-art control when combined with the AES Accu-Blend Control System.

    MIXER CAPACITIES
    MODEL MIXER CAPACITY
    POM -   30 22 -   103 MCFH @ 25-250 PSIG
    POM -  40 48 -   224 MCFH @ 25-250 PSIG
    POM -   60 84 -   393 MCFH @ 25-250 PSIG
    POM -   80 137 -   873 MCFH @ 25-250 PSIG
    POM -   100 206 - 1500 MCFH @ 25-250 PSIG
